68P80801E30-A 5/1/2002 4-25
Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
2. Starting at the first RF Cabinet, daisy-chain connect cables (PN
0112004Z29) from the ETHERNET OUT connectors to the
ETHERNET IN connectors on each cabinet junction panel in
accordance with Table 4-15 and Figures 4-9 through 4-12, as
applicable.
3. Connect a 50Ω BNC Termination (PN 0909906D01) to the
ETHERNET OUT connector on the last RF Cabinet in the
configuration.
4. Proceed to Alarm Intercabling.
