Gen 3 Site Controller System Manual Chapter 4 Installation
Intercabling Connections
800 MHz CAVITY COMBINING RFDS
1-5 Channel Omni • EAS/EAS2 RF#1 to Main RFC ALARM
connector on Power Supply Tray
Figure 4-15
6-10 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#2 to Expansion RFC ALARM
connector on Power Supply Tray
Figure 4-15
11-15 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#2 to Expansion RFC #1 ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#3 to Expansion RFC #2 ALARM
connector on Power Supply Tray
Figure 4-15
16-20 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#2 to Expansion RFC #1 ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#3 to Expansion RFC #2 ALARM
connector on Power Supply Tray
• High-Capacity EAS/EAS2 connection to
Expansion RFC #3 ALARM connector on Power
Supply Tray
Figure 4-15
Figure 4-17
Sectored • EAS/EAS2 RF#1 to Main RFC #1 ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#2 to Main RFC #2 ALARM
connector on Power Supply Tray
• EAS/EAS2 RF#3 to Main RFC #3 ALARM
connector on Power Supply Tray
Figure 4-16
900 MHz DUPLEXED RFDS
1-6 Channel Omni • EAS/EAS2 RF#1 to Main RFC alarm connector
on Rx Tray
Figure 4-14
7-12 Channel Omni Expansion • EAS/EAS2 RF#1 to Main RFC alarm connector
on Rx Tray
• EAS/EAS2 RF#2 to Expansion RFC alarm
connector on Rx Tray
Figure 4-14
Table 4-16 Alarm intercabling — continued
System/Site Type Intercabling Connections
Perform Cabling
As Shown In:
To Next Page
