Motorola MTH800 User Manual

5
Getting Started
Installing the Battery
1. Remove the battery from its protective clear plastic case.
2. If necessary, remove the battery cover as shown below.
3. Insert the battery top into the compartment as illustrated.
4. Carefully press the battery silver bottom downward until it
clicks into place.
5. Replace battery cover.
Replacing the Battery
1. To remove the battery cover, push down the cover button.
Slide the cover away.
2. Push retaining clip up and then lift the top of the battery out.
3. Replace the battery.
Charging the Battery
Motorola approved chargers provide optimum performance.
Other chargers may not fully charge your Motorola Lithium-
Ion battery or may reduce the life of the battery.
RETAINING CLIP

Motorola MTH800 Specifications

General

Frequency Range	380-430 MHz
Operating Temperature	-30°C to +60°C
Ingress Protection	IP54
RF Power Output	1W
Battery Type	Li-Ion
Channels	1000
