Motorola MTH800 User Manual

14
a personal issued radio. To use full access to the system user
needs to provide the login with the PIN number.
To login go to Menu > More... > RUI > Log on
You will see the screen as illustrated, where
you can type your User ID (up to 16
alphanumeric characters) and User PIN (up
to 6 numeric characters). Press select to
login. You should see the display with Log
On Accept.
How to Hold Your MTH800
The terminal has two microphones: a top microphone for
half-duplex dispatcher calls and a bottom microphone for full-
duplex telephone-like calls.
A call can be placed in high or low audio. To activate low or
high audio, see page 24.
In high audio the user transmits via the top microphone and
listens via the internal speaker.
In low audio the user speaks into the bottom microphone and
listens via the earpiece.
Group and Private Calls are half-duplex calls and can be
placed in high or low audio.
Phone, PABX, and full-duplex Private Calls are placed in low
audio. The speakerphone feature allows to hold Phone,
PABX, and full-duplex Private Calls via the MTH800 internal
speaker.
Use in Low Audio (Phone, PABX, and full-duplex Private
Calls)
When placing or receiving a call and while speaking, hold
your MTH800 as you would a telephone. Speak into the
bottom microphone. Listen via the earpiece.
Keep antenna at least 2.5 centimetres from your head and
body.
Back
Select
RUI Logon
User ID: __________
User PIN:

Motorola MTH800 Specifications

General

Frequency Range	380-430 MHz
Operating Temperature	-30°C to +60°C
Ingress Protection	IP54
RF Power Output	1W
Battery Type	Li-Ion
Channels	1000
