Operating the VC70 3 - 23
Waking the Vehicle Computer
The wakeup conditions define what actions wakeup the vehicle computer after it has gone into low power mode.
The vehicle computer can go into low power mode by either pressing the Power button on the Quick Access Panel
or automatically by control panel timeout settings. Tap >
Settings > Control Panel > Power icon > Wakeup tab.
These settings are configurable and the factory default settings are shown in Table 3-7.
Reduced Power Consumption
During the Reduced Power Consumption mode, the device is powered by the backup battery.
Table 3-8 shows the reduced power consumption mode active components.
Table 3-7 Wakeup Default Settings
Condition for Wakeup Power Button Automatic TimeOut
Keyboard No Yes
Touch Panel No No
Microphone PTT No Yes
Menu Key No Yes
USB Yes Yes
Table 3-8 Reduced Power Consumption Mode
VC70 Component Active
CPU On
Sensor Micro On
Display backlight Level 1
WLAN state (On) On (not connected)
WLAN state (connected) On (connected)
WLAN state (in PTT call) On (external speaker is
disconnected)
Bluetooth No change
Touch screen heater Off
RS232#1 5Vout Off
RS232#2 5Vout Off
USB#1 5Vout (external keyboard) Off
USB#2 5Vout Off
External RS232/USB peripherals Off
External speaker Off
External microphone On
