Appendix A Specifications
Technical Specifications
The following tables summarize the vehicle computer’s intended operating environment and general technical
hardware specifications.
Vehicle Computer
The following table summarizes the vehicle computer’s intended operating environment.
Table A-1
Technical Specifications
Item Characteristics
Physical and Environmental Characteristics
Dimension 11.5 in. L x 8.9 in. W x 2.4 in. D
291 mm L x 225.4 mm W x 60 mm D
Weight 9.4 lbs./4.3 kg
Keyboard Options 3 keyboards, all backlit with IP66 sealing and tactile feedback: QWERTY or AZERTY,
65-key with function keys F1-F24; side-mounted 21-key Numeric/Functional keypad
Power External IP66 sealed 9-60V DC/DC converter for all engines with 12V, 24V, 36V or 48V
truck battery; External 100-240VAC power supply for AC-powered carts
Integrated
Dual-function Battery
Provides up to 30 minutes session persistence during forklift battery swap and up to 72
hours RAM backup
Display 10.4 in. color XGA (1024 x 768) LCD; 600 NIT LED backlit; resistive touchscreen; auto
brightness control with ambient light sensor or manual control; motion sensing blanking
Interface Ports Standard sealed and secured connectors:
2 RS-232 serial ports (both with 5V/1.5A on pin 9)
2 USB port (host, both 5V/1.5A)
1 USB OTG (service)
CAN-Bus (J1939)
10/100Mbps Ethernet
