2 - 24 VC70 Vehicle Computer Product Reference Guide
Keyboard Protection Grill Installation
To protect the VC70 keyboard, it is recommended to install a protection grill. Different grills should be used with the
QWERTY/AZERTY or Numeric keyboard.
Each grill kit includes the following items:
•
Two Securing Strings
•
Keyboard Protection Grill
To install the grill:
1. Place the cover onto to the VC70 keyboard.
2. Use the two Securing Strings to attach the Protection Grill to the keyboard.
Figure 2-26
Keyboard Covers
Numeric Keyboard Protection Grill
QWERTY/AZERTY Keyboard Protection Grill
Securing
Strings
NOTE For Keyboard Protection Grills, refer to Accessories on page 1-4.
