NPort Server User’s Manual
5-30
Figure 5-5 shows you the application example to put the NPort Server at remote site
alone. Under this situation, there is no NT host to configure the port for RAS. Thus,
WAN port is the only possible configuration for these applications. You have to
configure the NPort Server at local before you can put that at remote site. Or, you
can connect a notebook besides the server for configuring the server before it can be
run under this environment. This may involves Access Control and Routings
besides WAN port settings.
Figure 5-5. WAN port application diagram - Standalone NPort Server at
remote site
NPortServer
203.67.6.253
192.167.1.11
NPort Server
Modem
Modem
Asynchronous Devices
