TN-5516/5518 User’s Manual Specifications
C-2
Alarm Contact Two relay outputs in one M12 A-coding 5-pin male connector
with current carrying capacity of 3 A @ 30 VDC or 3 A @ 240
VAC
Rotary Switches For setting the last 3 digits of the IP address
Power Requirements
Input Voltage LV: 12/24/36/48 VDC (8.4 to 60 VDC)
MV: 72/96/110 VDC (50.4 to 154 VDC)
HV: 110/220 VDC/VAC (88 to 300 VDC, 85 to 264 VAC)
Input Current TN-5500 Series:
0.338 A @ 24 VDC, 0.133 A @ 72 VDC, 0.089 A @ 110 VDC,
0.092 A @ 110 VAC, 0.047 A @ 220 VAC
TN-5518 Series:
0.507 A @ 24 VDC, 0.200 A @ 72 VDC, 0.134 A @ 110 VDC,
0.138 A @ 110 VAC, 0.071 A @ 220 VAC
Connection M23 5-pin male connector
Overload Current Protection Present
Reverse Polarity Protection Present
Physical Characteristics
Housing Metal, IP54 protection (with protective caps on unused ports)
Dimensions (W × H × D)
TN-5500 Series:
250 x 170 x 69.8 mm (9.84 x 6.69 x 2.75 in)
TN-5518 Series:
250 x 183 x 69.8 mm (9.84 x 7.20 x 2.75 in)
Weight TN-5500 Series: 2500g
TN-5518 Series: 2550 g
Installation Panel mounting, DIN-Rail mounting
(with optional kit)
Environmental Limits
Operating Temperature Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Humidity 5 to 95% (non-condensing)
Regulatory Approvals
Safety UL508 (Pending)
Rail Traffic EN50155, EN50121-3-2, EN50121-4 (Pending)
Road Traffic NEMA TS2 (Pending), e-Mark (Pending)
EMI FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), level 3
EN61000-4-3 (RS), level 4
EN61000-4-4 (EFT), level 3
EN61000-4-5 (Surge), level 3
EN61000-4-6 (CS), level 3
EN61000-4-8
EN61000-4-11
EN61000-4-12
Shock IEC61373
Freefall IEC60068-2-32
