TN-5516/5518 User’s Manual Featured Functions
3-79
Event Setup
Event Types can be divided into two basic groups: System Events and Port Events. System
Events are related to the overall function of the switch, whereas Port Events are related to the
activity of a specific port.
The TN-5500 supports two relay outputs. You can configure which relay output is related to which
events. This helps administrators identify the importance of the different events.
System Events Warning Relay output is triggered when…
Power Transition (OnÆOff) TN-5500 is powered on.
Power Transition (OffÆOn) TN-5500 is powered down.
Turbo Ring Break Turbo Ring is broken.
Port Events Warning e-mail is sent when…
Link-ON The port is connected to another device.
Link-OFF
The port is disconnected (e.g., the cable is pulled out,
or the opposing device shuts down).
Traffic-Overload
The port’s traffic surpasses the Traffic-Threshold for
that port (provided this item is Enabled).
Traffic-Threshold (%)
Enter a nonzero number if the port’s Traffic-Overload
item is Enabled.
Traffic-Duration (sec.)
A Traffic-Overload warning is sent every
Traffic-Duration seconds if the average
Traffic-Threshold is surpassed during that time
period.
