TN-5516/5518 User’s Manual EDS Configurator GUI
4-9
Import Configuration
The Import Configuration function is used to import an entire configuration from a text file to
the TN-5500. This utility can be used to transfer the configuration from one TN-5500 to another,
by first using the Export Configuration function (described in the previous section) to save a
switch configuration to a file, and then using the Import Configuration function. Perform the
following steps to import a configuration:
1. Highlight the server (from the Moxa switch list in the Configurator window’s left pane), and
then click the Import toolbar icon
, or select Import Configuration from the
Configuration menu.
2. Use the Open window to navigate to the text file that contains the desired configuration. Once
the file is selected, click Open to initiate the import procedure.
3. The Modify IP Address window will be displayed, with a special note attached at the bottom.
Parameters that have been changed will be activated with a checkmark. You may make more
changes if necessary, and then click OK to accept the changes.
