MP Aquinity 2 E - Page 98

Exploded view v.1.0.
2018.04.11HaSBI-Panel (180-0084)
a b c d e f g h
Plug socket 6 pole
860-1923
Aquinity²E / Aquinity²P /
Aquinity²P10 / Astacus²
BOTTOMSIDE - VIEW
FRONTSIDE - VIEW
CPU with Display
820-0725
Wall-mounting
830-0578
Housing
830-0577
USB
860-1996
Plug 6 pole (5 pins)
860-1922
