7 Commissioning
Maschinenfabrik Reinhausen GmbH 2018 595252433/02 EN ECOTAP
®
VPD
®
CONTROL PRO
7 Commissioning
This chapter describes how to commission the device.
NOTICE
Damage to device and system periphery
An incorrectly connected device can lead to damages in the device and sys-
tem periphery.
► Check the entire configuration before commissioning.
► Prior to commissioning, be sure to check the actual voltage and operating
voltage.
7.1 Performing tests
The following description does not apply if you have ordered the device ver-
sion with control cabinet. If that is the case, follow the description in the
ECOTAP VPD MD&C operating instructions.
Please contact Maschinenfabrik Reinhausen GmbH (MR) if any aspect of
the tests is not clear.
7.1.1 Ground test
For commissioning, carry out a ground test (check of the protective bonding
impedance) in accordance with IEC 61010-1. Observe the following informa-
tion when testing:
▪ Test current: 2 times the rated current of the overcurrent protection device
in the supply line.
▪ Test duration: 1 minute for each measurement point.
▪ The measured voltage between the measurement point and the protective
conductor must be less than 10V.
To carry out the ground test, proceed as follows:
► Apply the test current at the grounding terminal of the G1 PULS DIMEN-
SION QS3.241 assembly using a constant current source and measure
the voltage between the measurement point and the protective conductor.
ð The measured voltage must remain less than 10V for a period of 1
minute.
