Setting phase angle correction
You can use this parameter to set the phase angle correction for your trans-
former circuit. To do so, proceed as follows:
1. Go to Settings > Parameters > Transformer data > Phase angle cor-
rection.
2. Select the desired option.
3. Press the Accept button to save the modified parameter.
Setting measurement mode
If you are measuring the voltage and current with the 3-phase UI 3 measur-
ing module, you can use this parameter to set whether you have connected
the voltage transformer between 2 phases or between a phase and neutral.
To set the measuring mode, proceed as follows:
1. Go to Settings > Parameters > Transformer data > Measuring mode.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.
Also refer to
2 Setting UI measuring channels [►91]
8.6 Measurement
8.6.1 Setting UI measuring channels
If you are measuring the voltage and current with the 3-phase UI 3 measur-
ing module, you can use this parameter to set the measurement channels in
use:
Option Description
1-ph. measurement: Channel 1 The device uses 1 channel each for measure-
ment of voltage and current.
3-ph. measurement: Channel 1,
2, 3
The device uses 3 channels each for measure-
ment of voltage and current.
3-ph. voltage, 1-ph. current The device uses 3 channels for voltage measure-
ment and 1 channel for current measurement.
Table29: UI measuring channels
To set the UI measuring channels, proceed as follows:
1. Go to Settings > Parameters > Measurement > UI measuring chan-
nels.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.
