OPERATING AND MAINTENANCE MANUAL
Chapter 7 - Electronic controller
TAEevo Tech 015÷802 60 Hz UL
94
The data in this manual are not binding and they can be modified by the manufacturer without notice. Reproduction of this manual is strictly prohibited
ENGLISH
EN
Ar08 C Condenser anti-freeze heaters thermoregulation probe:
0= Disabled
1= Regulates common condenser water inlet probe
2= Regulates common condenser and condenser 1 / 2 water inlet
probe
3= Regulates condenser 1 / 2 water outlet probe
4= Regulates condenser 1 / 2 and common water outlet probe
5= Regulation on ambient air temperature
05
Ar09 C Switches on anti-freeze heaters when instrument is in remote OFF
or Stand-by:
0= Always off in remote OFF or Stand-by
1= On in remote OFF or Stand-by (switched on in accordance
with thermoregulator request)
01
Ar10 S Establishes operation of evaporator / condenser anti-freeze
heaters in case of fault of a probe dedicated to heaters control:
0= Off in case of probe fault
1= On in case of probe fault
01
Water heater function
Ar11 C Water heater function:
0= Disabled
1= Enabled with control in integration
2= Enabled with control in heating
02
Ar12 C Water heater elements activation ambient air setpoint. -50.0
-58
110.0
230
°C
°F
Dec
Int
Ar13 C Water heater elements deactivation ambient air differential. 0.1
0
25.0
45
°C
°F
Dec
Int
Ar14 C Water heater elements activation time lag. 0 250 Min
Water heater operation in chiller mode
Ar15 C Water heater elements setpoint in chiller mode. -50.0
-58
110.0
230
°C
°F
Dec
Int
Ar16 C Water heater elements proportional band in chiller mode. 0.1
0
25.0
45
°C
°F
Dec
Int
Water heater operation in heat pump mode
Ar17 C Water heater elements setpoint in heat pump mode. -50.0
-58
110.0
230
°C
°F
Dec
Int
Ar18 C Water heater elements proportional band in heat pump mode. 0.1
0
25.0
45
°C
°F
Dec
Int
Ar19 C Compressors off ambient air setpoint in integration mode. -50.0
-58
110.0
230
°C
°F
Dec
Int
Ar20 C Compressors on ambient air differential in integration mode. 0.1
0
25.0
45
°C
°F
Dec
Int
Anti-freeze alarm
Ar21 C Anti-freeze alarm thermoregulation probe in chiller mode:
0= Disabled
1= Regulation on evaporator inlet
2= Regulation on evaporator outlet 1/2
3= Regulation on evaporator outlet 1/2 and common outlet
4= Regulation on temperature Ambient air
04
Ar22 C Anti-freeze alarm thermoregulation probe in heat pump mode:
0= Disabled
1= Regulation on evaporator inlet
2= Regulation on evaporator 1 / 2 outlet
3= Regulation on evaporator outlet 1 / 2 and common outlet
4= Regulation on Ambient Air Temp.
04
Ar23 C Condenser anti-freeze alarm thermoregulation probe:
0= Disabled
1= Regulates common condenser water inlet probe
2= Regulates common condenser and condenser 1 / 2 water inlet
probe
3= Regulates condenser 1 / 2 water outlet probe
4= Regulates condenser 1 / 2 and common water outlet probe
5= Regulation on ambient air temperature
05
Parameter Level Description Min. Max. UM Resolution
