MTU 8V2000M40A - Engine - Main Dimensions

3.24 Engine – Main dimensions
Main engine dimensions
Engine model Length (A) Width (B) Height (C)
8V 2000 M40A / M40B approx. 2005mm approx. 1280mm approx. 1315mm
12V 2000 M40A /
M40B / M41A /M41B
approx. 2106mm approx. 1398mm approx. 1291mm
16V 2000 M40A /
M40B / M41A /M41B
approx. 2815mm approx. 1425mm approx. 1291mm
MS150031/06E 2016-010 | Technical Data | 109
TIM-ID: 0000002145 - 003
