7.8 Fuel System
7.8.1 HP fuel line – Pressure pipe neck replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Open-end wrench bit
F30025897 1
Spider patch spanner
F30027425 1
Spider patch spanner
F30027424 1
Double-head box wrench
F30011450 1
Ratchet adapter
F30027340 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260
Engine oil
Pressure pipe neck
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
• Never direct air jet at people.
• Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Remove cylinder head cover (→ Page 158).
2. Drain fuel (→ Page 169).
MS150031/06E 2016-010 | Fuel System | 167
TIM-ID: 0000004678 - 007
