7.6.2 Injection pump – Removal and installation
Preconditions
Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Ratchet adapter
F30027340 1
Box wrench
F30038493 1
Spider patch spanner
F30027424 1
Spider patch spanner
F30027425 1
Torque wrench, 0.5-5 Nm
0015384230 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
DANGER
Rotating and moving engine parts.
Risk of crushing, danger of parts of the body being caught or pulled in!
Before cranking the engine with starter system, make sure that there are no persons in the engine's
danger zone.
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
Avoid open flames, electrical sparks and ignition sources.
Do not smoke.
Wear protective clothing, protective gloves, and safety glasses / facial protection.
Preparatory steps
1. Close fuel supply line upstream of fuel filter.
2. Remove engine control system (→ Page 224).
3. Drain fuel (→ Page 169).
4. Remove charge-air pipes and all seals.
160 | Injection Pump / HP Pump | MS150031/06E 2016-010
