7.7.2 Injector – Removal and installation
Preconditions
Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Puller
3555890163/00 1
Fuel suction device
F30378207 1
Torque wrench, 20-100 Nm
F30026582 1
Ratchet adapter
F30027340 1
Open-end wrench bit
F30025897 1
Spider patch spanner
F30027425 1
Spider patch spanner
F30027424 1
Double-head box wrench
F30011450 1
Ratchet adapter
F30027340 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
Avoid open flames, electrical sparks and ignition sources.
Do not smoke.
Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
Never direct air jet at people.
Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Remove cylinder head cover (→ Page 158).
2. Drain fuel (→ Page 169).
164 | Injection Valve / Injector | MS150031/06E 2016-010
