Item Color Inscription Meaning / Function
11 White START Pressing the pushbutton initiates the automatic engine start se-
quence.
LED (spot) lights up as long as the starting procedure is running.
12 Green LOCAL CONTROL Pressing the switch activates changeover between local and remote
control mode.
LED (spot) lights up when local mode is active.
13 Green READY FOR OPER-
ATION
Pressing the switch causes changeover between “Not ready for op-
eration” and “Ready for operation” status.
LED (spot) lights up at "Ready for operation" switch position.
14 Green (None) (None)
15 Green (None) (None)
16 Green (None) (None)
17 White ALARM AC-
KNOWLEDGE
Pressing the key the first time stops alarm signalization.
Pressing the button a second time acknowledges an active alarm.
LED (spot) lights up when an alarm is active.
18 White DIM ↑ Holding down the key increases LCD background illumination.
19 White F1 Function keys to control the man-machine interface.
Functions vary and are displayed on the LCD screen.
20 White F2
MS150031/06E 2016-010 | Operation | 111
TIM-ID: 0000008856 - 006
