Description of Setup Buttons (Administrator Settings) 17-25
17
[Color Registration Adjust]
To display: [Utility] - [Administrator Settings] - [System Settings] - [Expert Adjustment] - [Color Registration
Adjust]
Adjust the print position for each paper type with respect to each color if color shifts are detected in the print
result.
Load paper into the Bypass Tray and press Start to start printing the test pattern. Make adjustments while
checking the test pattern. Repeat adjustments as necessary.
The example shows the color registration adjustment for cyan.
Settings Description
[X] If the print position of the desired color is out of line to the left or right with
respect to the printing position of black, tap [-] and [+] to enter an adjust-
ment value in the range between -6 dots and +6 dots.
• [-]: Move the print position to the left.
• [+]: Move the print position to the right.
[0 dot] is specified by default.
[Y] If the print position of the desired color is shifted up or down with respect
to the printing position of black, tap [-] and [+] to enter an adjustment value
in the range between -6 dots and +6 dots.
• [-]: Move the print position down.
• [+]: Move the print position up.
[0 dot] is specified by default.
