EN
W415-2912 / E / 06.02.21
47
fi nishing
DOOR WITH
SAFETY
BARRIER
4” (101.6mm)
6” (152.4mm)
2” (50.8mm)
0” (0mm)
5” (127mm)
3”(76.2mm)
10.2 fi nishing with non-combustibles
Safety Barrier
4”
• Non-combustible fi nish material must not project more than 4” (101.6mm) from the front of the fi replace outer
shell. If greater projections are desired, increase the clearance to the sides, bottom and top by 2” (50.8mm)
for every additional 1” (25.4mm) of projection. If using an optional surround, the same rules applies, starting
from the top of the surround. Ensure clearances are maintained for surround removal, as it must lift off of
appliance for maintenance.
!
WARNING
