Nautel Vector-LP VR125 - RF Power Module Securing Hardware

Page 5-10 Vector-LP Radio Beacon Transmitter Technical Instruction Manual
Issue 1.1 Section 5 Maintenance and Troubleshooting
Figure 5-1: RF Power Module Securing Hardware
TOP COVERS: Remove five M4
screws from top cover for each RF
power module. Reinstall this
hardware after module replacement
SHIPPING SCREWS: Remove two M4
screws from bottom for each RF power
module. NOTE: Shipping screws may have
been removed during installation. They are
not required after module replacement.
