Nautel Vector-LP VR125 - Family Tree - Vector-LP Radio Beacon Transmitter

Vector-LP Radio Beacon Transmitter Technical Instruction Manual Page 7-5
Section 7 Parts Information Issue 1.1
Figure 7-1: Family Tree – Vector-LP Radio Beacon Transmitter
F2050001 VG
A15
RF POWER PROBE
NAPF07B/01
* VR125 only
A14
RF FILTER
NAPF09* (536-1250 kHz, 1600-1800 kHz)
NAPF05 (190 - 535 kHz)
A12A2
SWITCH MODE POWER SUPPLY
NAPS31B/03 (NAP35/01)
NAPS31B/02 (NAP35)
A6
INTERPHASE PDM DRIVER
NAPM11
A2
EXCITER INTERFACE
NAPI76A/02
A13A2
SWITCH MODE POWER SUPPLY
NAPS31B/03 (NAP35/01)
NAPS31B/02 (NAP35)
(DUAL NDB)
A8
RF SYNTHESIZER PWB
NAPE70C
(OPTIONAL)
A4
SITE INTERFACE
NAPI79 OR NAPI80
A12
RF POWER MODULE
NAP35/01 (125/D200)
NAP35 (250/D375)
A12A4
MODULATOR FILTER
NAPF06
A12A5
MODULATOR
NASM11
VECTOR - LP
NARB18
(DUAL NDB/DGPS)
A10
EXTERNAL MONITOR/GENERATOR PWB
NAPE76A/03
A13A4
MODULATOR FILTER
NAPF06
(OPTIONAL)
A16
BATTERY BOOST ASSEMBLY
205-8035
A12A1
CONTROL/INTERFACE
NAPC151
A13A1
CONTROL/INTERFACE
NAPC151
A7
EXTERNAL MONITOR/GENERATOR PWB
NAPE76A/03
(NDB)
A5
RF SYNTHESIZER PWB
NAPE70C
A3
REMOTE INTERFACE
NAPI78B/02
A1
CONTROL/DISPLAY PWB
NAPC147B
(DUAL NDB/DGPS)
A13
RF POWER MODULE
NAP35/01 (125/D200)
NAP35 (250/D375)
A12A3
POWER AMPLIFIER
NAAA06
A13A3
POWER AMPLIFIER
NAAA06
A13A5
MODULATOR
NASM11
(DUAL NDB/DGPS)
A9
INTERPHASE PDM DRIVER
NAPM11
A11
INTERFACE PWB
NAPI94
A16A1
BATTERY BOOST PWB
NAPS35
