Vector-LP Radio Beacon Transmitter Technical Instruction Manual Page 3-9
Section 3 Operating Instructions Issue 1.1
Table 3-3: Exciter Interface PWB Controls and Indicators
REF DES
PANEL
MARKING
DESCRIPTION
E1, E2,
E3, E8,
E9
Key CW
Jumpers
Shorting jumpers that are installed in positions determined by
the type of transmitter. In NDB transmitters, the jumpers are
factory installed in position 2. No user adjustment is required.
E4, E5,
E6, E7,
E10, E11
DGPS/BEACON
Jumpers
Bi-position selection jumpers that are installed in positions
determined by the type of transmitter. In NDB transmitters,
the jumpers are factory installed to short pins 2 and 3. No
user adjustment is required.
