Dimensions = mm (inches)
Block Diagram – RF Power Stage Issue 1.1 Not to Scale Figure 6-4 Page 6-25 (6-26 Blank)
B A
B A
B2050103 VA
DC POWER
(OPTIONAL)
RELAY CONTROL
+VDC
RF DRIVE(B), PDM(B)
RF DRIVE(A), PDM(A)
RF POWER MODULE
OUTPUT B
RF POWER MODULE
OUTPUT A
RF FILTER
+VDC
AC POWER
FROM AC/DC POWER STAGE
FROM EXCITER/
SERIAL LINK, CONTROL/MONITOR
MONITOR
RF OUTPUT TO RF POWER PROBE
MODULE
RF POWER
SERIAL LINK, CONTROL/MONITOR
CONTROL/MONITOR BLOCK
MODULE
RF POWER
FROM AC/DC POWER STAGE
TO EXCITER/ CONTROL/MONITOR BLOCK
