Nautel Vector-LP VR125 - Page 145

195-3019
Display Mod
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
J01 JQ55Conn, Header, Ribbon Cbl, 20Pin 103308-5 00779
U01 UT81Display,LCD,240x60 Graphic,Ext Temp C10815(STATIC)
PACIFIC DISPLAY
DEVICES
36AB3
195-3023
Ribbon Cable Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
W16P01 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W16P02 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
195-3032
Modem Kit
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
U04 UW66Modem, Industrial, V.92 Data/Fax MT5634IND 62959
205-1016
Cableform Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
P01 JP65Conn,Rcpt Housing,12 Pin,Metrimate 211759-1 09482
P02 JT50Conn, Plug, 3-Pin, Mate-N-Lok 350766-1 00779
P03 JT50Conn, Plug, 3-Pin, Mate-N-Lok 350766-1 00779
P04 JT50Conn, Plug, 3-Pin, Mate-N-Lok 350766-1 00779
205-1018
Ribbon Cable Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
W1P1 JP50Conn, Recept, Ribbon Cable, 10 pin 746285-1 00779
W1P2 JP50Conn, Recept, Ribbon Cable, 10 pin 746285-1 00779
W2P1 JP50Conn, Recept, Ribbon Cable, 10 pin 746285-1 00779
W2P2 JP50Conn, Recept, Ribbon Cable, 10 pin 746285-1 00779
W3P1 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W3P2 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
Page 1 of 89
205-1018
