Nautel Vector-LP VR125 - Page 149

205-8019
Ribbon Cable Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
W01P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W01P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W02P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W02P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W03P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W03P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W04P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W04P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W05P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W05P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W06P1 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W06P2 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W06P3 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W07P1 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W07P2 JP45Conn, Recept, Ribbon Cable, 20 pin 746288-4 00779
W10P1 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
W10P2 JP51Conn, Recept, Ribbon Cable, 40 pin 746288-9 00779
205-8035
Battery Boost Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
A01 NAPS35SMPS, 24/48V Battery Boost PWB Assy 205-7020 37338
C01 CS11Capacitor, Plastic, 1.0uF 10PC 250V B32232A3105K EPCOS
C02 CS22Capacitor, Metal,Polyprop, 5uF +/-10% 100V 5MP12D505K 50558
CR06 QH43Diode, Fast Recovery, 600V, 60A DSEI60-06A 0A5K5
Q04 QR56Transistor,FET,N,500V,0.1 Ohm STW26NM50(STATIC) 0G343
Q05 QR56Transistor,FET,N,500V,0.1 Ohm STW26NM50(STATIC) 0G343
TB01 JF27Terminal Block, 4-Pos, Double, 61A G10/4 5Y407
205-8073
Wire Assy Cabinet Vector-LP
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
J1 JT52Conn, Coax, Jack, N, Crimp for RG303 24-N-50-3-11C/133 0GZ58
P2 JDP22Conn, Coax, N, Plug, 50ohm, Crimp, RG58 82-5375 02660
Page 5 of 89
205-8073
