NEC PA721X User Manual

101
5. Using On-Screen Menu
TIP:
Thehorizontalpositionandverticalpositionaretheamountofmovementfromthereferencepoints.Forexample,whenTOP-LEFT
isadjusted,thepositionisdisplayedwiththesameamountofmovementevenifdisplayedwithotherstartingpositions.
Themaximumamountofmovementishalftheresolutionoftheprojector.
Referencepoint
Adjustusingthehorizon-
talposition
Sub-display Maindisplay
Referencepoint
Adjustusingtheverticalposition
TOP-LEFT TOP-RIGHT
BOTTOM-LEFT BOTTOM-RIGHT
ReferencepointReferencepoint
BORDER
Selectthedisplayboundaryofthemaindisplayandsub-displayofthe[PICTUREBYPICTURE]screen.
Displayboundary
Maindisplay
Sub-displayMaindisplay
Sub-display
MaindisplaySub-display
TIP:
• ForWUXGAtype,sixstepscanbeselected.
• ForWXGAtype/XGAtype,threestepscanbeselected.
