2. Projecting an Image (Basic Operation)
TIP:
• Thediagrambelowshowsthelensshiftadjustmentrange(projectionformat:desk/front)oftheWUXGAtype(excludingthelens
unitNP30ZL).Usethetiltfootifyouwishtoraisetheprojectionpositionbeyondthis.(→ page 25)
• RefertoPage257forthelensshiftadjustmentrangeoftheWXGAtype/XGAtypeandforceilinghanging/frontprojection.
100%V
50%V
10%V
100%H
30%H 30%H
10%H 10%H
Heightofprojectedimage
Widthofprojectedimage
PA622U/PA522U
 Descriptionofsymbols:Vindicatesvertical(heightoftheprojectedimage),Hindicateshorizontal(widthoftheprojectedim-
age).
Focus
Applicablelens:NP12ZL/NP13ZL/NP14ZL/NP15ZL
UsetheFOCUSringtoobtainthebestfocus.
Focusring
