172

6. Installation and Connections

6. Closetheltercover.

 Afterclosing,pushtheltercovernearthebuttonsuntila“click”

soundisheard.Theltercoverwillbesecuredinposition.

Button

To remove the wireless LAN unit

1. Remove the ﬁlter unit following steps 1 to 3 above.

WIRELESS

2. Remove the wireless LAN unit.

 IfthewirelessLANunitishardtoremove,placeacloth,etc.,

overneedle-noseplierstograspthewirelessLANunitandpull

itout.

NOTE:DonotgraspthewirelessLANunitwithexcessiveforce.Doing

so will damage it.

3. Mount the ﬁlter unit and ﬁlter cover as described in steps

5 and 6 above.
