2. Projecting an Image (Basic Operation)

❺ Adjusting the Picture Size and Position

Usethelensshiftdial,theadjustabletiltfootlever,thezoomlever/zoomringandthefocusringtoadjustthepicture

sizeandposition.

Inthischapterdrawingsandcablesareomittedforclarity.

Adjustingtheprojected image’s vertical and horizontal

position

[Lensshift]

(→page21)

Adjustingthefocus

[Focusring]

(→page22)

Finelyadjustingthesizeofanimage

[Zoomlever/Zoomring]

(→page25)

Adjusting the projected image’s height and horizontal

tilt

[Tiltfoot]*¹

(→page25)

NOTE*

:Adjusttheprojectedimage’sheightusingthetiltfeetwhenyouwanttoprojecttheimageatapositionhigherthanthelens

shift adjustment range.

NEC PA721X User Manual
