2. Projecting an Image (Basic Operation)

Adjusting the Tilt Feet

1. Turn the left and right tilt feet to adjust.

 Thetiltfeetlengthenandshortenwhenturned.

 Theheightoftheprojectedimageisadjustedbyturningtheleftand

righttiltfeet.

 Iftheprojectedimageistilted,turnoneofthetiltfeettoadjustthe

imagesothatitislevel.

• Iftheprojectedimageisdistorted,see“3-6CorrectingHorizontal

andVerticalKeystoneDistortion[CORNERSTONE]”(→page35)

and“[GEOMETRICCORRECTION]”(→page102).

• Thetiltfeetcanbelengthenedbyamaximumof20mm.

• Thetiltfeetcanbeusedtotilttheprojectorbyamaximumof4°.

NOTE:

• Donotlengthenthetiltfeetanymorethan20mm/0.8".Doingsowillmakethe

tiltfeet’smountsectionunstableandcouldcausethetiltfeettocomeoffthe

projector.

• Donotuse thetiltfeetfor anypurposeotherthan adjustingtheprojector’s

projection angle.

 Handlingthetiltfeetimproperly,suchascarryingtheprojectorbygraspingthe

tilt feet or hooking it onto a wall using the tilt feet, could damage the projec-

tor.

Zoom

Turnthezoomleverorzoomringclockwiseandcounterclockwise.

• TheseparatelysoldNP11FLlensdoesnothaveazoomring.

Zoomring

Tiltfoot

Down
