257
10. Appendix
Lens shifting range
Thisprojectorisequippedwithalensshiftfunctionforadjustingthepositionoftheprojectedimagebyturningthelens
shiftdials.Thelenscanbeshiftedwithintherangeshownbelow.
NOTE:
• ThelensshiftfunctioncannotbeusedwhenusingtheNP11FLlens.
• Pleasedonotusethelensshiftfunctionwhenprojectingportraitimages.Pleaseuseitwiththelensinthecenter.
* Refertothelensshifttableonthenextpageforthedrawingnumberofthelensshiftrange.
Desk/frontprojection
100%V
100%H
1
2
3
4
10%H 10%H
Widthofprojectedimage
Heightofprojectedimage
Descriptionofsymbols:Vindicatesvertical(heightoftheprojectedimage),Hindicateshorizontal(widthofthepro-
jectedimage).
Ceiling/frontprojector
100%V
100%H
10%H
10%H
1
2
3
4
Heightofprojectedimage
Widthofprojectedimage
