161

6. Installation and Connections

HDMI IN

AUDIO IN

HDMI OUT

AUDIO OUT

Connecting an External Monitor

Youcanconnectaseparate,externalmonitortoyourprojectortosimultaneouslyviewonamonitorthecomputer

analogimageyou’reprojecting.

• PleaserefertoPage67whendisplayingthe[PIP/PICTUREBYPICTURE]screen.

NOTE:

• WhenoutputtingHDMIsignals,turnonthepowerofthevideodeviceontheoutputsideandkeepitconnectedbeforeinputting

videosignalsintothisdevice.TheHDMIoutputterminalsoftheprojectorareequippedwithrepeaterfunctions.Whenadeviceis

connectedtotheHDMIoutputterminal,theresolutionoftheoutputsignalislimitedbytheresolutionsupportedbytheconnected

device.

• ConnectinganddisconnectinganHDMIcableorselectinganotherinputsourceonthesecondandsubsequentprojectorswill

disabletheHDMIrepeaterfunction.

• InthecaseoftheHDMIoutputterminaloftheprojector,thetheoreticalnumberofunitsthatcanbeconnectedinaseriesisseven.

Themaximumnumberofunitsthatcanbeconnectedmaybereducedbytheexternalenvironmentandqualityofthesignaland

cable,etc.ThenumberofunitsthatcanbeconnectedmaydifferdependingontheHDCPversion,restrictiononthenumberof

HDCPrepeatersinthesourcedeviceandthequalityofthecable.Theoverallsystemneedstobecheckedinadvancewhenbuild-

ing a system.

• Whenaudioequipmentisconnected,theprojectorspeakerisdisabled.

• Tooutputaudiofromtheaudiooutputterminalwhentheinputterminalisneither“COMPUTERIN”nor“BNCIN”,select[BNC]

under[AUDIOSELECT]oftheon-screenmenu.

• Whenthe[STANDBYMODE]issetto[NORMAL],videoandaudiowillnotbeoutputwhentheprojectorissettothestandby

mode.Setthestandbymodeto[NETWORKSTANDBY]forMMmodels.ForHDBaseTmodels,setthestandbymodeto[HDBaseT

STANDBY],turnonthepowersupplytothetransmissiondeviceandkeeptheunitinaconnectedstate.

• ForHDBaseTmodels,HDMIsignalswillnotbeoutputwhenthe[STANDBYMODE]oftheprojectorissetto[NORMAL].Tooutput

aHDMIsignal,setthe[STANDBYMODE]to[HDBaseTSTANDBY],turnonthepowersupplyofthetransmissiondeviceandkeep

the unit in a connected state.

• Boththecompositevideosignalfromeachinputconnectorasthecomputer,BNC,andBNC(CV),andtheS-videosignalfrom

theBNC(Y/C)InputconnectorarenotoutputfromHDMIOUTConnectorofthisprojector.

Computercable(VGA)

(notsupplied)

Stereomini-plugaudiocable

(notsupplied)

HDMIcable(notsupplied)
