142
IEEE802.11n Draft2.0
Item Specification
Conforming standard IEEE802.11n Draft2.0 *1
Communication mode
(send)
65/58.5/52/39/26/19.5/13/6.5 (Mbps mode) @20MHz
72.22/65/57.78/43.33/28.89/21.67/14.44/7.22 (Mbps mode)
@20MHz, short GI enabled
135/121.5/108/81/54/40.5/27/13.5(Mbps mode) @40MHz
150/135/120/90/60/45/30/15 (Mbps mode)
@40MHz, short GI enabled *2
Communication mode
(receive)
130/117/104/78/52/39/26/13 (Mbps mode) @20MHz
144.44/130/115.56/86.67/57.78/43.33/28.89/14.44 (Mbps mode)
@20MHz, short GI enabled
270/243/216/162/108/81/54/27 (Mbps mode) @40MHz
300/270/240/180/120/90/60/30 (Mbps mode)
@40MHz, short GI enabled *2
Modulation method OFDM and MIMO methods
Wireless channels 1 to 11ch (active scanning)
12ch, 13ch (passive scanning) *3
36ch, 40ch, 44ch, 48ch, 52ch, 56ch, 60ch, 64ch, 100ch, 104ch, 108ch,
112ch, 116ch, 120ch, 124ch, 128ch, 132ch, 136ch, 140ch
(passive scanning) *3
Frequency band 2.4GHz band (2.4 to 2.4835GHz)
5GHz band (5.15 to 5.35GHz, 5.47 to 5.725GHz)
*1: "Conforming to IEEE802.11n Draft2.0" does not secure connectability with other products
supporting IEEE802.11n Draft.
*2: These communication modes are based on the theoretical communication rate in the standard
and thus do not match effective rates. Such factors as connected devices, radiowave environment,
surrounding obstacles, installation environment, usage status and used OS, applications and
software may affect communication rate and distance.
*3 It may take much time to connect US40a to a passive scanning channel.
