Appendix C
Specification
Item Specification
CPU VIA C7-M ULV 1.2GHz
Chipset VIA CN896, 8237A (for Core) & ITE 8512 (for KB controller)
MEM Dual DDRII-SODIMM sockets for 512MB (2GB)
Display 15.4" WXGA TFT (1280 x 800)
Storage DOM : 2GB
Pointing device Touch Pad with 2 buttons
Express card Express card 34/54
LAN Integrated 10/100BASE-TCommunications
Wireless LAN 802.11 a/b/g/n
I/O Ports 3 x USB2.0
1 x Express Card 34/54 slot
1 x Smart Card reader
1 x 15 pin D-sub connector (RGB) for external monitor
1 x Headphone-out phone jack
1 x Monaural MIC-in phone jack for external Microphone
1 x RJ-45 jack for LAN
1 x DC-in jack
External Dimension(mm) 370(W) × 260(D) × 36(H)
Weight 2.45 kg
AC Adapter 75W
Power Consumption 30W
Temperature 10 to 35ºCEnvironmental
Requirement
Humidity 20 to 80% (no condensation)
OS Windows XP Embedded
OS (Virtual PC) Windows XP, Windows Vista
OS (Terminal Service) Windows Server 2003, Windows Server 2008
