The login page displays.
3.
In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
4.
Select Configure > Security.
The Security page displays.
5.
In the RADIUS Server Settings section, do one of the following:
•
Enable 802.1X access authentication: Turn on the 802.1x Access
Authentication button so that it displays green and is positioned to the right.
CAUTION: Before you enable 802.1X access authentication, manually set the
port authentication mode of the uplink port or ports to Authorized (see Manage
port authentication for individual ports on page 63).
•
Disable 802.1X access authentication: Turn off the 802.1x Access
Authentication button so that it displays gray and is positioned to the left.
This is the default setting.
6. Click the Apply button.
Your settings are saved.
7.
To save the settings to the running configuration, at the top of the page, click the
Save icon or text.
Remove port authentication from individual
ports
After you remove port authentication form a port, the switch allows traffic on the port
without authentication.
To remove port authentication mode from individual ports:
1. Launch a web browser.
2.
In the address field of your web browser, enter the IP address of the switch.
The login page displays.
Audio Video User Manual65Security
AV Line of Fully Managed Switches M4250 Series
