NETGEAR R6350 User Manual

Table 1. LED and button descriptions (Continued)
DescriptionLED and Button
Solid green.The WiFi radio is operating.
Off.The WiFi radios are off.
WiFi
Solid green. A USB device is connected and is ready.
Off. No USB device is connected.
USB
Ports, Buttons, and Connectors on the Back Panel
The back panel of the router provides ports, buttons, antenna connectors, and a DC power connector.
Figure 2. Router back panel
In addition to the three antenna connectors, viewed from left to right, the back panel contains the following
components:
• USB port. Use the USB 2.0 port (which is labeled USB 2.0-Printer) to connect the router to a USB
device such as a printer. (A USB 3.0 port is located on the front panel.)
• Ethernet LAN ports. Use the four Gigabit Ethernet RJ-45 LAN ports to connect the router to LAN
devices.
• WAN port. Use the yellow Gigabit Ethernet RJ-45 WAN port to connect the router to a modem.
• WPS button. Use this button to connect WPS-enabled devices to the router.
• Reset button. For information about using the Reset button, see Return the Router to Its Factory Default
Settings on page 122.
• Power On/Off button. Press the Power On/Off button to provide power to the router.
• DC power connector. Connect the power adapter that came in the product package to the DC power
connector.
Hardware Overview of the Router
12
AC1750 Smart WiFi Router Model R6350

NETGEAR R6350 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Product type	Tabletop router
Product color	Black
Power source type	AC
Package depth	328 mm
Package width	250 mm
Package height	96 mm
Package weight	930 g
Number of products included	1 pc(s)
Cables included	LAN (RJ-45)
Processor frequency	880 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit AES, WPA, WPA2-PSK
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity	3
Shipping (inner) case width	529 mm
Shipping (inner) case height	364 mm
Shipping (inner) case length	315 mm
Shipping (inner) case net weight	6760 g
Number of layers per pallet (air)	3 pc(s)
Number of layers per pallet (sea)	5 pc(s)
Number of cartons per pallet layer	6 pc(s)

Weight and Dimensions

Depth	150.76 mm
Width	235.51 mm
Height	54.5 mm
Weight	377 g
