NETGEAR R6350 User Manual

Access a Storage Device Connected to the Router From a
Windows-Based Computer
To access the USB storage device from a Windows-based computer:
1. Connect a USB storage device to a USB port on your router.
2. If your USB storage device uses a power supply, connect it.
You must use the power supply when you connect the USB storage device to the router.
When you connect the USB storage device to the router’s port, it might take up to two minutes before
it is ready for sharing. By default, the USB storage device is available to all computers on your local
area network (LAN).
3. Select Start > Run.
4. Enter \\readyshare in the dialog box.
5. Click the OK button.
A window automatically opens and displays the files and folders on the USB storage device.
Access a Storage Device That Is Connected to the Router From
a Mac
From a computer or device on the network, you can access a storage device that is connected to the router.
To access the device from a Mac:
1. Connect a USB storage device to a USB port on your router.
2. If your USB storage device uses a power supply, connect it.
You must use the power supply when you connect the USB storage device to the router.
When you connect the USB storage device to the router’s port, it might take up to two minutes before
it is ready for sharing. By default, the USB storage device is available to all computers on your local
area network (LAN).
3. On a Mac that is connected to the network, select Go > Connect to Server.
The Connect to Server window opens.
4. In the Server Address field, enter smb://readyshare.
5. When prompted, select the Guest radio button.
If you set up access control on the router and you allowed your Mac to access the network, select the
Registered User radio button and enter admin for the name and router admin password for the password.
For more information about access control, see Allow or Block Access to Your Network on page 63.
6. Click the Connect button.
A window automatically opens and displays the files and folders on the USB storage device.
Share USB Storage Devices Attached to the Router
79
AC1750 Smart WiFi Router Model R6350

NETGEAR R6350 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Product type	Tabletop router
Product color	Black
Power source type	AC
Package depth	328 mm
Package width	250 mm
Package height	96 mm
Package weight	930 g
Number of products included	1 pc(s)
Cables included	LAN (RJ-45)
Processor frequency	880 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit AES, WPA, WPA2-PSK
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity	3
Shipping (inner) case width	529 mm
Shipping (inner) case height	364 mm
Shipping (inner) case length	315 mm
Shipping (inner) case net weight	6760 g
Number of layers per pallet (air)	3 pc(s)
Number of layers per pallet (sea)	5 pc(s)
Number of cartons per pallet layer	6 pc(s)

Weight and Dimensions

Depth	150.76 mm
Width	235.51 mm
Height	54.5 mm
Weight	377 g
