Play Music From a Storage Device With iTunes Server
iTunes server lets you play music from a USB device that is connected to a USB port on your router with
iTunes on your Windows-based or Mac computer or with the Apple Remote app on your iPhone or iPad.
You can also use the Apple Remote app from an iPhone or iPad to play music on any AirPlay devices, such
as Apple TV or AirPlay-supported receivers.
Supported music file formats are MP3, AAC, and FLAC.The maximum number of music files supported is
10,000.
Set Up the Router’s iTunes Server With iTunes
You can play music from a USB device that is connected to your router with iTunes on your Windows or
Mac computer using Home Sharing. To set up Home Sharing, you need an Apple account and the latest
version of iTunes installed on your computer.
To set up the router’s iTunes server to play music on iTunes:
1. Connect a USB storage device to a USB port on your router.
2. If your USB storage device uses a power supply, connect it.
You must use the power supply when you connect the USB storage device to the router.
When you connect the USB storage device to the router’s USB port, it might take up to two minutes
before it is ready for sharing. By default, the USB storage device is available to all computers on your
local area network (LAN).
3. Launch a web browser from a computer or mobile device that is connected to the router network.
4. Enter http://www.routerlogin.net.
A login window opens.
5. Enter the router admin user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
6. Select ADVANCED > USB Storage > ReadySHARE > Media Server.
The Media Server (Settings) page displays.
7. Select the Enable iTunes Server (Music Only) check box.
8. Click the Apply button.
Your settings are saved.
9. On your Windows-based or Mac computer, launch iTunes.
10. Select File > Home Sharing > Turn On Home Sharing.
The Home Sharing page displays.
11. Enter your Apple ID email address and password.
12. Click the Turn On Home Sharing button.
Use the Router as a Media Server
97
AC1750 Smart WiFi Router Model R6350

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6350 and is the answer not in the manual?

NETGEAR R6350 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1750 Mbit/s
Product typeTabletop router
Product colorBlack
Power source typeAC
Package depth328 mm
Package width250 mm
Package height96 mm
Package weight930 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Processor frequency880 MHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, WPA, WPA2-PSK
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity3
Shipping (inner) case width529 mm
Shipping (inner) case height364 mm
Shipping (inner) case length315 mm
Shipping (inner) case net weight6760 g
Number of layers per pallet (air)3 pc(s)
Number of layers per pallet (sea)5 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth150.76 mm
Width235.51 mm
Height54.5 mm
Weight377 g
