Page #86 background imageLoading...
Page #86 background image
View or Change Network Folders on a Storage Device
You can view or change the network folders on a storage device connected to the router.
To view or change network folders:
1. Launch a web browser from a computer or mobile device that is connected to the router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > USB Storage > ReadySHARE.
The USB Storage (Advanced Settings) page displays.
5. Scroll down to the Available Networks Folder section and adjust the following settings:
• Share Name. If only one USB device is connected, the default share name is USB_Storage.
You can click the name or you can type it in the address field of your web browser. If Not Shared
is shown, the default share was deleted and no other share for the root folder exists. Click the link
to change this setting.
• Read Access and Write Access. Show the permissions and access controls on the network folder.
All–no password (the default) allows all users to access the network folder.The password for admin
is the same one that you use to log in to the router.
• Folder Name. Full path of the network folder.
• Volume Name. Volume name from the storage device.
• Total Space and Free Space. Show the current utilization of the storage device.
6. Click the Apply button.
Your settings are saved.
Add a Network Folder on a USB Storage Device
You can add network folders on a USB storage device connected to a router USB port.
To add a network folder:
1. Launch a web browser from a computer or mobile device that is connected to the router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
Share USB Storage Devices Attached to the Router
86
AC1750 Smart WiFi Router Model R6350

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6350 and is the answer not in the manual?

NETGEAR R6350 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1750 Mbit/s
Product typeTabletop router
Product colorBlack
Power source typeAC
Package depth328 mm
Package width250 mm
Package height96 mm
Package weight930 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Processor frequency880 MHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, WPA, WPA2-PSK
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity3
Shipping (inner) case width529 mm
Shipping (inner) case height364 mm
Shipping (inner) case length315 mm
Shipping (inner) case net weight6760 g
Number of layers per pallet (air)3 pc(s)
Number of layers per pallet (sea)5 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth150.76 mm
Width235.51 mm
Height54.5 mm
Weight377 g
