6. Select the Traffic volume control by radio button.
7. From the corresponding menu, select an option:
• Download only.The restriction is applied to incoming traffic only.
• Both Directions.The restriction is applied to both incoming and outgoing traffic.
8. In the Monthly Limit field, enter how many MBytes (MB) per month are allowed.
9. If your ISP charges you for extra data volume when you make a new connection, enter the extra data
volume in MB in the Round up data volume for each connection by field.
10. In the Traffic Counter section, set the traffic counter to begin at a specific time and date.
11. In the Traffic Control section, enter a value in minutes to specify when the router issues a warning
message before the monthly limit in hours is reached.
This setting is optional.The router issues a warning when the balance falls below the number of minutes
that you enter. By default, the value is 0 and no warning message is issued.
12. Select one or more of the following actions to occur when the limit is reached:
• Turn the Internet LED to flashing green. This setting is optional. When the traffic limit is reached,
the Internet LED blinks alternating green and amber.
• Disconnect and disable the Internet connection.This setting is optional. When the traffic limit is
reached, the Internet connection is disconnected and disabled.
13. Click the Apply button.
Your settings are saved and the router restarts.
The Internet Traffic Statistics section helps you to monitor the data traffic.
Restrict Internet Traffic by Connection Time
You can record and restrict the traffic by connection time. This is useful when your ISP measures your
connection time.
To record and restrict the Internet traffic by connection time:
1. Launch a web browser from a computer or mobile device that is connected to the router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > Traffic Meter.
The Traffic Meter page displays.
5. Select the Enable Traffic Meter check box.
6. Select the Connection time control radio button.
Manage Your Router
130
AC1750 Smart WiFi Router Model R6350
