NETGEAR R6350 User Manual

Manage Port Forwarding to a Local Server for Services
and Applications
If a server is part of your network, you can allow certain types of incoming traffic to reach the server. For
example, you might want to make a local web server, FTP server, or game server visible and available to
the Internet.
The router can forward incoming traffic with specific protocols to computers on your local network.You can
specify the servers for applications and you can also specify a default DMZ server to which the router
forwards all other incoming protocols (see Set Up a Default DMZ Server on page 102).
Forward Incoming Traffic for a Default Service or Application
You can forward traffic for a default service or application to a computer on your network.
To forward incoming traffic for a default service or application:
1. Decide which type of service, application, or game you want to provide.
2. Find the local IP address of the computer on your network that will provide the service.
The server computer must always receive the same IP address.To specify this setting, use the reserved
IP address feature. See Manage Reserved LAN IP Addresses on page 107.
3. Launch a web browser from a computer or mobile device that is connected to the router network.
4. Enter http://www.routerlogin.net.
A login window opens.
5. Enter the router user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
6. Select ADVANCED > Advanced Setup > Port Forwarding / Port Triggering.
The Port Forwarding / Port Triggering page displays.
7. Make sure that the Port Forwarding radio button is selected.
8. From the Service Name menu, select the service or application.
If the service or application that you want to add is not in the list, create a port forwarding rule with a
custom service or application (see Add a Port Forwarding Rule With a Custom Service or Application
on page 155).
9. In the Internal IP Address field, enter the IP address of the computer that must provide the service or
that runs the application.
10. Click the Add button.
Your settings are saved and the rule is added to the table.
Manage Port Forwarding and Port Triggering
154
AC1750 Smart WiFi Router Model R6350

NETGEAR R6350 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Product type	Tabletop router
Product color	Black
Power source type	AC
Package depth	328 mm
Package width	250 mm
Package height	96 mm
Package weight	930 g
Number of products included	1 pc(s)
Cables included	LAN (RJ-45)
Processor frequency	880 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit AES, WPA, WPA2-PSK
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity	3
Shipping (inner) case width	529 mm
Shipping (inner) case height	364 mm
Shipping (inner) case length	315 mm
Shipping (inner) case net weight	6760 g
Number of layers per pallet (air)	3 pc(s)
Number of layers per pallet (sea)	5 pc(s)
Number of cartons per pallet layer	6 pc(s)

Weight and Dimensions

Depth	150.76 mm
Width	235.51 mm
Height	54.5 mm
Weight	377 g
