Test the LAN Path to Your Router
You can ping the router from your computer to verify that the LAN path to your router is set up correctly.
To ping the router from a Windows-based computer:
1. From the Windows toolbar, click the Start button and select Run.
2. In the field provided, type ping followed by the IP address of the router, as in this example:
ping www.routerlogin.net
3. Click the OK button.
You see a message like this one:
Pinging <IP address > with 32 bytes of data
If the path is working, you see this message:
Reply from < IP address >: bytes=32 time=NN ms TTL=xxx
If the path is not working, you see this message:
Request timed out
If the path is not functioning correctly, one of the following problems might be occurring:
• Wrong physical connections
For a wired connection, make sure that the numbered LAN port LED is lit for the port to which you are
connected.
Check to see that the appropriate LEDs are lit for your network devices. If your router and computer are
connected to a separate Ethernet switch, make sure that the link LEDs are lit for the switch ports that
are connected to your computer and router.
• Wrong network configuration
Verify that the Ethernet card driver software and TCP/IP software are both installed and configured on
your computer.
Verify that the IP address for your router and your computer are correct and that the addresses are on
the same subnet.
Test the Path From a Windows-Based Computer to a Remote
Device
To test the path from a Windows-based computer to a remote device:
1. From the Windows toolbar, click the Start button and select Run.
2. In the Windows Run window, type
ping -n 10 <IP address>
where <IP address> is the IP address of a remote device such as your ISP DNS server.
If the path is functioning correctly, messages display that are similar to those shown in Test the LAN
Path to Your Router on page 170.
3. If you do not receive replies, check the following:
Troubleshooting
170
AC1750 Smart WiFi Router Model R6350

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6350 and is the answer not in the manual?

NETGEAR R6350 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1750 Mbit/s
Product typeTabletop router
Product colorBlack
Power source typeAC
Package depth328 mm
Package width250 mm
Package height96 mm
Package weight930 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Processor frequency880 MHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, WPA, WPA2-PSK
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity3
Shipping (inner) case width529 mm
Shipping (inner) case height364 mm
Shipping (inner) case length315 mm
Shipping (inner) case net weight6760 g
Number of layers per pallet (air)3 pc(s)
Number of layers per pallet (sea)5 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth150.76 mm
Width235.51 mm
Height54.5 mm
Weight377 g
