Remove All QoS Rules
You can permanently remove all custom and default QoS rules.
WARNING:
If you remove all QoS rules, both the custom and default QoS rules are
permanently removed.The only way to get the default QoS rules back is by
returning the router to factory default settings.
To remove all QoS rules:
1. Launch a web browser from a computer or mobile device that is connected to the router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The password is the one that you specified the first time that you logged in.
The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > QoS Setup.
The QoS Setup page displays.
WARNING:
If you click the Delete All button, all default and custom QoS rules are
permanently removed.
5. Click the Delete All button.
All QoS rules are permanently removed.
6. Click the Apply button.
Your settings are saved.
Manage Uplink Bandwidth Control
Uplink bandwidth control lets you check the maximum uplink bandwidth that your Internet connection can
support and specify the maximum uplink bandwidth.
To specify the maximum uplink bandwidth:
1. Launch a web browser from a computer or mobile device that is connected to the router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
Optimize Performance
43
AC1750 Smart WiFi Router Model R6350

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6350 and is the answer not in the manual?

NETGEAR R6350 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1750 Mbit/s
Product typeTabletop router
Product colorBlack
Power source typeAC
Package depth328 mm
Package width250 mm
Package height96 mm
Package weight930 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Processor frequency880 MHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, WPA, WPA2-PSK
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity3
Shipping (inner) case width529 mm
Shipping (inner) case height364 mm
Shipping (inner) case length315 mm
Shipping (inner) case net weight6760 g
Number of layers per pallet (air)3 pc(s)
Number of layers per pallet (sea)5 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth150.76 mm
Width235.51 mm
Height54.5 mm
Weight377 g
