Page #17 background imageLoading...
Page #17 background image
Connect to the Network
You can connect to the router’s network through a wired or WiFi connection. If you set up your computer to
use a static IP address, change the settings so that it uses Dynamic Host Configuration Protocol (DHCP).
Wired Connection
You can connect your computer to the router using an Ethernet cable and join the router’s local area network
(LAN).
To connect your computer to the router with an Ethernet cable:
1. Make sure that the router is receiving power (its Power LED is lit).
2. Connect an Ethernet cable to an Ethernet port on your computer.
3. Connect the other end of the Ethernet cable an Ethernet port on the router.
Your computer connects to the local area network (LAN).
WiFi Connection
To find and select the WiFi network:
1. Make sure that the router is receiving power (its Power LED is lit).
2. On your computer or WiFi device, find and select the WiFi network.
The WiFi network name is on the router label.
3. Join the WiFi network and enter the WiFi password.
The password is on the router label.
Your device connects to the WiFi network.
WiFi Connection Using WPS
You can connect to the router’s WiFi network with Wi-Fi Protected Setup (WPS) or you can find and select
the WiFi network.
To use WPS to connect to the WiFi network:
1. Make sure that the router is receiving power (its Power LED is lit).
2. Check the WPS instructions for your WPS-enabled device.
3. Press the WPS button on the router.
4. Within two minutes, on your WPS-enabled device, press its WPS button or follow its instructions for
WPS connections.
Your cWPS-enabled device connects to the WiFi network.
Connect to the Network and Access the Router
17
AC1750 Smart WiFi Router Model R6350

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6350 and is the answer not in the manual?

NETGEAR R6350 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1750 Mbit/s
Product typeTabletop router
Product colorBlack
Power source typeAC
Package depth328 mm
Package width250 mm
Package height96 mm
Package weight930 g
Number of products included1 pc(s)
Cables includedLAN (RJ-45)
Processor frequency880 MHz
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit AES, WPA, WPA2-PSK
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Antennas quantity3
Shipping (inner) case width529 mm
Shipping (inner) case height364 mm
Shipping (inner) case length315 mm
Shipping (inner) case net weight6760 g
Number of layers per pallet (air)3 pc(s)
Number of layers per pallet (sea)5 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth150.76 mm
Width235.51 mm
Height54.5 mm
Weight377 g
