NETGEAR WNDAP360 User Manual

Installation and Basic Configuration
20
ProSafe Dual Band Wireless-N Access Point WNDAP360
 To configure time settings:
1. Select Configuration > System > Basic > Time. The Time screen displays:
Figure 9.
2. Specify the fields as explained in the following table:
3. Click Apply
to save your settings.
Table 3. Time System Settings
Field Description
Time Zone Select the time zone to match your location.
Current Time This is a nonconfigurable field that
displays the current date and time.
NTP Client Enable the Network Time Protocol (NTP) client to synchronize the time of the
wireless access point with an NTP server. By default the Enable radio button is
selected.
Use Custom NTP Server Select this check box to If you wan
t to use a custom NTP server.
Note: You need to have an Internet connection to use an NTP server that is
not
on your local network.
Hostname /
IP Address
Enter the host name or IP address of
the custom NTP server.
The default is time-b.netgear.com.
Note: If you use a host name, make sure that you have
configu
red a DNS server. For more information, see the next
section.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
