NETGEAR WNDAP360 User Manual

Installation and Basic Configuration
22
ProSafe Dual Band Wireless-N Access Point WNDAP360
3. Click Apply to save your settings.
The wireless access point provides a built-in DHCP serve
r for wireless clients only, which can
be especially useful in small networks. When the DHCP server is enabled, the wireless
access point provides preconfigured TCP/IP configurations to all connected wireless stations.
 To configure DHCP server settings:
1. Select Confi
guration > IP > DHCP Server Settings. The DHCP Server Settings screen
displays:
Figure 11.
2. Specify the fields as explained in the following table:
Table 5. DHCP Server Settings
Field Description
Select the DHCP Serv
er check box to enable the DHCP server. Use the default settings or specify the pool
of IP addresses to be assigned by setting the starting IP address and ending IP address. These addresses
should be part of the same IP address subnet as the wireless access point’s LAN IP address.
DHCP Server VLAN ID Enter the DHCP server VLAN ID. The VLAN ID range is between 1 and 4094.
Starting IP Address Enter the first address in the range of IP addresses to be assigned to DHCP
cl
ients. The default address is 192.168.1.02.
Ending IP Address Enter the last address in the range of IP addresses to be assigned to DHCP
cl
ients. The default address is 192.168.1.50.
Subnet Mask Enter the subnet mask to be used by DHCP clie
nts. The default mask is
255.255.255.0.
Gateway IP Address Enter the IP address of the default routing gateway to be used by DHCP clients.
T
he default address is 192.168.0.1.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
