NETGEAR WNDAP360 User Manual

Advanced Configuration
88
ProSafe Dual Band Wireless-N Access Point WNDAP360
3. Specify the settings as explained in the following table:
Table 25. EDCA Settings
Field Description
AP EDCA parameters
AIFS Enter the Arbitration Inter-Frame Spacing (AIFS) int
erval that specifies the wait time (in
milliseconds) between data frames. A higher AIFS value means a higher priority for a
queue. Valid values for AIFS are 0 through 8.
The default values are: Data 0: 3; Dat
a 1: 7; Data 2: 1; Data 3: 1.
cwMin Enter the Minimum Contention Window (cwMin) value that specifies the upper limit (in
milliseconds) of a range from which the initial random back-off wait time is determined.
Decreasing this value increases the priority of the queue. The value for cwMin needs to be
lower than the value for cwMax. Valid values are 0, 1, 3, 7, 15, 31, 63, 127, 255, 511, or
1023.
The default values are: Data 0: 15; Data 1: 15; Data 2: 7; Data 3: 3.
cwMax Enter the Maximum Contention Window (cwMax)
value that specifies the upper limit (in
milliseconds) for the doubling of the random back-off value. Decreasing this value
increases the priority of the queue. The value for cwMax needs to be higher than the value
for cwMin. Valid values are 0, 1, 3, 7, 15, 31, 63, 127, 255, 511, or 1023.
The default values are: Data 0: 63; Data 1: 1023; Data 2: 15; Data 3: 7.
Max. Burst Enter the maximum burst value that specifies the maximum burst
length (in microseconds)
allowed for packet bursts on the wireless network. A packet burst is a collection of multiple
frames transmitted without header information. Decreasing this value increases the priority
of the queue. Valid values for maximum burst length are all multiples of 32 between 0 and
8192, inclusive of 0 and 8192.
The default values are: Data 0: 0; Data 1: 0; Data 2: 3008; Data 3: 1504.
Station EDCA parameters
AIFS Enter the Arbitration Inter-Frame Spacing (AIFS) int
erval that specifies the wait time (in
milliseconds) between data frames. A higher AIFS value means a higher priority for a
queue. Valid values for AIFS are 0 through 8.
The default values are: Data 0: 3; Dat
a 1: 7; Data 2: 2; Data 3: 2.
cwMin Enter the Minimum Contention Window (cwMin) value that specifies the upper limit (in
mil
liseconds) of a range from which the initial random back-off wait time is determined.
Decreasing this value increases the priority of the queue. The value for cwMin needs to be
lower than the value for cwMax. Valid values are 0, 1, 3, 7, 15, 31, 63, 127, 255, 511, or
1023.
The default values are: Data 0: 15; Data 1: 15; Data 2: 7; Data 3: 3.

NETGEAR WNDAP360 Specifications

General

VLAN support	Yes
Frequency band	2.4 - 5 GHz
Number of users	50 user(s)
Cabling technology	10/100/1000BASE-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Antenna connector type	SMA
Antenna gain level (max)	5 dBi
Weight (imperial)	1.93 lbs
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE802.1x
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, EAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, TTLS, WEP, WPA, WPA2
Power requirements	12 VDC, 1A
Power consumption (typical)	10.51 W
Minimum system requirements	Internet Explorer 6.0, Mozilla Firefox 1.5
Compatible operating systems	- Windows Vista, XP, 2000, 98, Me - Mac OS - UNIX - Linux
Internal	No
LED indicators	LAN
Cable lock slot type	Kensington

Weight and Dimensions

Height	54.76 mm
Weight	878 g
Dimensions (WxDxH)	253.75 x 253.76 x 54.76 mm
